I have 10+ years of university-level education.

But no lecture taught me how to create good visualizations.

These things are crucial for communication but are often not part of the training.

So, let's have a crash course on visualization guidelines anyone can implement. 🧵

1. Know your audience

You can't use the same visualization for every audience.

A plot that works in a scientific journal may bore (or confuse) non-scientists.

2. Know your takeaways

Forget the dream of putting ALL of your great insights into one powerful plot.

This. does. not. work.

If anything, this dream is a gateway to using too many chart types all at once.

Visualize only your most important insights (maybe in separate plots).

3. Use only a few chart types in one plot

A bar chart here. Add a line there. Include some points and text labels over there. And all of a sudden you've got a mess.

Here's a SWD makeover reducing the number of chart types. Looks cleaner, right?

Source: storytellingwithdata.com/blog/bar-chart…

4. Be mindful of your color use

Colors are great. But they can easily overwhelm your reader.

There are two similar rules of thumb that can help to avoid that:

- Start with grey
- Emphasize just one or a few categories

5. Avoid rainbow colors

They can turn into a colorful rainbow mess pretty quickly.

Here are my go-to alternatives palettes:

Coloors generator: coolors.co/d9f4c7-f8fa90-…
Viridis: sjmgarnier.github.io/viridis/index.…
Okabe-Ito: mikemol.github.io/technique/colo…

6. Reduce clutter

Do you really need all labels? Or all grid lines or axes? Especially with labeled bar charts there is really no need to keep it all.

7. Align labels

Your plot feels more harmonious if labels are aligned and not spread out all over the place.

For example, what feels "smoother" in this image?

Remember that next time you create a table with centered columns.

8. Remove the legend and label directly

Do you really need a legend? It can take up sooo much valuable space of your plot.

Besides, switching back and forth from the legend to the plot can be quite challenging for your reader.

Instead, you can label directly.

These were just a few of my most favorite dataviz "rules".

Of course, there's lots more to learn.

So let's talk resources.

Fundamentals of Data Visualization by @ClausWilke is a great resource to learn more about dataviz.

Best part? It's totally free and open-source.

clauswilke.com/dataviz/

Another great and totally free resource is

Data Visualization: A practical introduction by @kjhealy

socviz.co/index.html#pre…

I've also enjoyed the Storytelling with Data book.

It's pretty short but filled with insights. Unfortunately, it's not free.

storytellingwithdata.com/books

Now, it's one thing to know the rules but it's another thing to apply them.

My recommendation? Practice with the weekly #tidyTuesday challenge.

Each week, a new data set for practicing your data skills is published.

A great competition for all levels. github.com/rfordatascienc…

If you're getting started with visualizations, you'll likely need help.

But don't worry, there are resources for templates/inspiration. Here are my 4 favorite helpers:

1️⃣ cookbook-r.com/Graphs/

2️⃣ r-graph-gallery.com

3️⃣ python-graph-gallery.com

4️⃣ data-to-viz.com

That's a wrap for today.

I hope that you enjoyed this little intro to data visualization 😊

What are your favorite dataviz rules? How did you learn about them? 🤔

Thanks, @cmuirmath, for pointing out that I could have mentioned an important rule:

Make your plots accessible. This can include:

- colorblind-friendly colors (like the above Okabe-Ito, Viridis colors)

- Double-coding (e.g. use color AND shape for categories)

- Add alt-text
