Sometimes the nose radome of a Panther would be separated from the aircraft during arrested landing.

"VF-91 F9F-2 lands aboard the USS Philippine Sea (CVA-47) in 1953."

📖📷mikesresearch.com/2020/06/28/gru… 👁‍🗨 Mike's Research Image
Same incident.

"Lt(JG) Hugh N. Batten lands his damaged Grumman F9F-2 Panther after it was hit by enemy anti-aircraft fire. Photo dated 12 July 1953. This plane's nose covering has been entirely torn away.…"

📷📖history.navy.mil/our-collection… 👁‍🗨 @USNHistory
🔗commons.wikimedia.org/wiki/File:Dama… Image
"VF-781 F9F-2B (tail code D) lands aboard the USS Bon Homme Richard (CV-31) in 1951."

📷📖mikesresearch.com/2020/06/28/gru… 👁‍🗨 Mike's Research Image
Of course, sometimes, other parts broke loose too…

📷 👁‍🗨 @SDASM

• • •
