➡️ Combining Tabas and Raad ambush SAM systems in the yet unknown SAM system (left photo)
Lets take a look at the features of Raad-3/Tabas-2 (whatever its called), some of which are unique 1/2
Main feature is passive engagement capability of the Raad system, which combines infrared volume search with a long-range laser-range-finder
➡️ It allows passive engagement up until the last seconds before SAM impact, when it switches to terminal SARH mode and radar is turned on
In the new system, infrared search cameras are likely mounted on the mast, putting it at higher position
On the photo, the mast only mounts the long-range directional data-link antenna, which is a very important capability of the system.
It relies on upper-echelon early warning
- Shahab-3
- Ghadr (if non-sub-munition & no "evader MaRV")
- Sejil-2 (if non-sub-munition & no "evader MaRV")
- Emad (if no "evader MaRV")
- Dezful (if no "evader MaRV")
- Qiam-2
- Rezvan (at reduced range/coverage)
⬇️
Arrow-2 (-1) effective against (2/2):
- Khorramshahr-2 (if non-sub-munition & no "evader MaRV")
- Khorramshahr-4 *
-Haj-Qasem *
- Kheybar-Shekan *
- Fattah-1 (at point defense range/coverage or launch on remote of several interceptors)
