Have you found the concept of Decision Trees confusing? Well, this thread would be useful!
A beginner-friendly DETAILED explanation to Decision Trees ๐๐งต
A beginner-friendly DETAILED explanation to Decision Trees ๐๐งต
๐ What is a Decision Tree?
It is a Classification Algorithm. Decision Trees can use it to solve Regression problems as well. It is a tree or graph-like structure with a root node, non-leaf nodes, leaf nodes and branches.
See an example of Decision Tree using AND Table (Image)
It is a Classification Algorithm. Decision Trees can use it to solve Regression problems as well. It is a tree or graph-like structure with a root node, non-leaf nodes, leaf nodes and branches.
See an example of Decision Tree using AND Table (Image)
Let's understand two terms first:-
What is splitting?
Splitting is dividing the nodes into two or more sub-nodes based on the outcome. In the "Yes or No" case, a node will split into two sub-nodes, one pointing towards the outcome of YES & the other towards NO.
What is splitting?
Splitting is dividing the nodes into two or more sub-nodes based on the outcome. In the "Yes or No" case, a node will split into two sub-nodes, one pointing towards the outcome of YES & the other towards NO.
What is impurity?
When a node doesn't have a clear outcome or doesn't belong to a single class, whether it be Yes Class or No Class, the node is impure.
If the node has all the values of a single class, it is called a pure node.
When a node doesn't have a clear outcome or doesn't belong to a single class, whether it be Yes Class or No Class, the node is impure.
If the node has all the values of a single class, it is called a pure node.
How to select which feature to do a split?
For that, we calculate the impurity. We want to select the feature which gives us the lowest impurity.
Lowest impurity means that the split will result in producing "less" impure nodes.
For that, we calculate the impurity. We want to select the feature which gives us the lowest impurity.
Lowest impurity means that the split will result in producing "less" impure nodes.
We aim to reach pure nodes, where each node belongs to a single class.
-> How do we calculate impurity?
The most common method is GINI INDEX. It is used for BINARY SPLIT (splitting in yes or no).
Other measures include:-
Accuracy
Information Gain
Gain Ratio
The most common method is GINI INDEX. It is used for BINARY SPLIT (splitting in yes or no).
Other measures include:-
Accuracy
Information Gain
Gain Ratio
๐ Formula to calculate GINI INDEX
GI = 1 - square of(Probability of "Yes") - square of(Probability of "No)
GI = 1 - square of(Probability of "Yes") - square of(Probability of "No)
๐ Let's take a table to understand the working of the decision tree:-
We have a table with Independent Variables such as Chest Pain, Good Blood Circulation & Blocked Arteries, determining the Heart Disease variable, a dependent variable.
Refer to the image
We have a table with Independent Variables such as Chest Pain, Good Blood Circulation & Blocked Arteries, determining the Heart Disease variable, a dependent variable.
Refer to the image
In the data above, we have named four features: Chest Pain, Good Blood Circulation & Blocked Arteries, which we can make our root node.
To decide which node to make the root, we calculate the Gini Index and pick the lowest impurity feature.
To decide which node to make the root, we calculate the Gini Index and pick the lowest impurity feature.
Let's say,
If we pick Chest Pain:-
If Chest Pain YES -> 105 People have Heart Disease, and 39 don't have Heart Disease.
If Chest Pain NO -> 34 People have Heart Disease, and 125 don't have Heart Disease.
For other features, see the image:-
If we pick Chest Pain:-
If Chest Pain YES -> 105 People have Heart Disease, and 39 don't have Heart Disease.
If Chest Pain NO -> 34 People have Heart Disease, and 125 don't have Heart Disease.
For other features, see the image:-
Gini Index for when Chest Pain is YES
= 1 - sq of(Prob of Heart Disease Yes) - sq of(Prob of Heart Disease No)
= 1 - sq of(105/105+39) - sq of(39/105+39)
= 0.395
Gini Index for when Chest Pain is No = 0.336
Now, we calculate the Total Gini Index for Yes & No Chest Pain.
= 1 - sq of(Prob of Heart Disease Yes) - sq of(Prob of Heart Disease No)
= 1 - sq of(105/105+39) - sq of(39/105+39)
= 0.395
Gini Index for when Chest Pain is No = 0.336
Now, we calculate the Total Gini Index for Yes & No Chest Pain.
๐ Total G.I. = Weighted average of Gini Impurities for leaf nodes
Total G.I. for Chest Pain Node = [(Chest Pain Yes/Total Chest Pain Patients) x G.I ofChest Pain Yes] + [(Chest Pain No/Total Chest Pain Patients) x G.I ofChest Pain No]
= [(144/144+159) x 0.395] + [(159/144+159) x 0.336)]
= 0.364
= [(144/144+159) x 0.395] + [(159/144+159) x 0.336)]
= 0.364
After calculating the Gini Index of each feature like this, we would find that the Good Blood Circulation feature has the lowest impurity. Thus, we select that feature to be our root node.
Similarly, we continue the process to find the next node and complete our Decision Tree.
Similarly, we continue the process to find the next node and complete our Decision Tree.
If you liked the explanation of A DECISION TREE as a Machine Learning Algorithm, consider following me, like this tweet and retweet it as well.
Thank you :)
Thank you :)
