Proposed COVID-19 Pathophysiology [Part 2 of 3]:

Enter the magnificent macrophage.

What do #COVID-19 and hemophagocytic lymphohistiocytosis (#HLH) potentially have in common?

...let’s continue our journey onward into the cytokine storm.
First, let’s briefly summarize what we covered before:

What mechanism may be partly responsible for heterogeneity of COVID-19 disease phenotype as well as its severity?
Correct! Antibody-dependent enhancement (ADE) is the result of producing sub-neutralizing antibodies which paradoxically enhance the rate of viral replication and severity of viremia.
Part of the vascular injury seen in COVID-19 may be a product of which of the following:
All of the above may be at play in the generation of the immune response and subsequent tissue damage:

What happens to immune complexes after deposition?

Macrophage (M0) phagocytosis→ antigen presentation → cytokine release → TH1 response → CD8+ T and B-cell ab response
Of note, the severity of this response is proportional to the amount of antibody-antigen complex present.

Now for those that may not know, what is hemophagocytic lymphohistiocytosis (HLH)?
HLH is a M0 hyperactivation syndrome!

It results in catastrophic cytokine production (“cytokine storm”)

It also leads to hemophagocytosis, where M0s ultimately begin consuming the body’s own red blood cells / WBCs to a pathological level (see below)
Incredibly simply put, it is thought to be stimulated by a multi-hit process, where a pre-existing condition such as cancer, autoimmune disease, or infection meets a triggering event, often severe infection.

(Its full pathophysiology will be a tweetorial for another day.)
What is the hallmark laboratory finding (often dramatic) in HLH?
Ferritin is often considerably elevated, with levels >3000 strongly suggestive of developing HLH.

Where does this marked rise ferritin come from in HLH?
M0s serve as master regulators of iron metabolism - every iron molecule in your body passes through them.

Ferritin is released from M0s to help facilitate the starvation of bacterial pathogens of free iron (hence why it is an acute phase reactant / part of the cytokine response)
Generally speaking, what cytokines are produced by M0s?

Well...it depends on their polarization!

M0s wear multiple hats. Their function depends on the surrounding environment and physiological need.

They can act both as promoters or regulators of inflammation.
The polarization of macrophages is a complex process, but is simplified as follows:

M0s have two main phenotypes - M1 and M2. Think of them as the ninja janitors ("ninjanitors") of your body:

M1 = Pro-inflammatory ninja!

M2 = Anti-inflammatory janitor!
M1 release of pro-inflammatory cytokines, namely:

IL-1 → Fever + acute phase response + IL-2/TH2 response

IL-6 → Fever + acute phase response + antibody production

TNF-a → Further M0 activation + inc. cytokine production

IFN-y → Cell priming + M0 & T-cell activation
M2 produce anti-inflammatory cytokines (i.e. IL-4, IL-10, and TGF-beta) that facilitate tissue repair & promote angiogenesis.

Do parts of this seem familiar? They should.

The cytokine profile seen in HLH mirrors what is seen in COVID-19 because both create a robust M1 response!
And what's the purpose of an M1 response?

1. Cull other M0s, T-cells, and B-cells! This is to promote a humoral response, generating antibodies. It also

2. Self-promotes itself, creating a positive feedback cycle which continues until it

3. Eradicates the pathogen
Negative feedback of this M1 response depends on generation of a humoral response and removal of the inciting stimulus.

T-cells play an equally important role in viral regulation as well as the generation of an appropriate B-cell antibody response.
...but what happens if your lymphocyte response is hindered?

We know that the severity of lymphopenia is correlated with the severity of disease in COVID-19.

()

With⬇️lymphs, regulating both worsening viremia and the M1 response would be more difficult.
Thus, viral-mediated lymphocyte destruction may contribute to the HLH-like phenotype:

⬇️ T and B-cells = blunted humoral response:

⬇️Ab titers-> ⬆️ sub-neutralizing antibody response -> ⬆️ viremia

⬇️ Negative feedback + ⬆️viremia --> M1 hyperactivation

sciencedirect.com/science/articl…
As loss of control of viremia occurs, more viral particles would be taken up into M0s, further driving M1 phenotype and a pro-inflammatory response!

Note: All positive feedback cycles end in an explosion.

In this case, the explosion = widespread pulmonary inflammation / injury!
TL;DR:

▶️COVID-19 and HLH share considerable similarities in their cytokine patterns, reflecting M1 hyperactivation.

▶️Lymphopenia may be due to direct viral invasion; this correlates with disease severity.

▶️Loss of TH1 / T-reg response may lead to constitutive M1 activation.
▶️Loss of B-cells may lead to loss of humoral response → greater ADE → greater severity of viremia

▶️Uncontrolled viremia is taken up by M0, further driving M1 phenotype

▶️Positive M1 feedback cycle = IL-1, IL-6, TNF-a, INF-y → “cytokine storm” → vascular endothelial damage
Further points of clarification here, thanks to a great discussion by @angrybiomed1:
